Xiaomi Redmi 10X 4G Standard Edition Dual SIM TD-LTE CN 128GB M2003J15SC (Xiaomi Merlin)

Osnovno

Datum izlaska

2020-05-27

Brend

Xiaomi

Model

Redmi 10X 4G Standard Edition Dual SIM TD-LTE CN 128GB M2003J15SC

Najavljen

2020 May 26

Dizajner hardvera

Xiaomi

Kodna oznaka

Xiaomi Merlin

Dodatna oprema

Haptic touch feedback

Kategorija

Smartphone

Kućište

Masa

199 g

Širina

77.2 mm

Visina

162.3 mm

Debljina

8.9 mm

Zapremina kućišta

111.5 ccm

Ekran

Tip

Color IPS TFT LCD display

Dijagonala

6.53 inča

Rezolucija

1080x2340

Gustina

395 ppi

Display Hole

1-hole

Rezolucija

1080x2340

Širina ekrana

69.5 mm

Visina ekrana

150.59 mm

Horizontal Full Bezel Width

7.7 mm

Površina ekrana

10467 square millimeter

Display Area Utilization

83.5%

Pixel Size

0.06436 mm/pixel

Gustina piksela

395 PPI

Tip ekrana

Color IPS TFT LCD display

Dubina boja

24 bit/pixel

Number of Display Scales

16.8M

Display Dynamic Range Depth

8 bit/pixel

Osvetljenje ekrana

LED

Display Light Reflection Mode

Da

Display Subpixel Scheme

Da

Display Refresh Rate

60 Hz

Zaštita ekrana

Corning Gorilla Glass 5

Graphical Controller

ARM Mali-G52MP2

GPU Clock:

1000 MHz

A/V Out

Ne

Platforma

Sistem

Android

Čip

mediatek-helio-g85-mt6769z

Takt procesora

2000 MHz

Procesor

MediaTek Helio G85 MT6769Z, 2020, 64 bit, octa-core, 12 nm, ARM Mali-G52 2EEMC2 GPU

Tip RAM memorije

LPDDR4x SDRAM

RAM

4096 MiB RAM

Non-volatile Memory Type

Flash EEPROM

Non-volatile Memory Interface

Da

Interna memorija

122070 MiB non-volatile

Memorija

RAM

4 GB

Interna

128 GB

Baterija

Kapacitet

5020 mAh

Battery

Lithium-ion

Nominal Cell Voltage (1st cell)

3.87 Volts

Nominal Cell Capacity (1st cell)

5020 mAh cell

Nominal Battery Voltage

3.87 Volts

Kapacitet baterije

5020 mAh battery

Nominal Battery Energy

19.43 Wh

Estimated Battery Life

17.0 hours

Estimated Average Current

295 mA

Talk Time:

33.0 hours

Current During Talk

152 mA

Market Countries

China

Softver

Platforma

Google Android

Operativni sistem

Google Android 10 (Q)

Softverske mogućnosti

Voice Command , Navigation software , Intelligent personal assistant , Face Recognition

Zvuk

Audio Channel(s)

stereo

Microphone(s)

stereo

Loudspeaker(s):

mono

Audio Output:

3.5mm

Supported Cellular Data Links

GPRS (Class unspecified) , EDGE (Class unspecified) , UMTS 384 kbps (W-CDMA) , HSUPA (Cat. unspecified) , HSUPA 5.76 Mbps (Cat. 6) , HSUPA 11.5 Mbps (Cat. 7) , HSDPA (Cat. unspecified) , HSPA+ 21.1 Mbps (Cat. 18) , DC-HSDPA 42.2 Mbps (Cat. 24) , cdmaOne (IS-95) , CDMA2000 1xRTT (IS-2000) , CDMA2000 1xEV-DO Rel. 0 , TD-SCDMA , TD-HSDPA , LTE (Cat. unspecified) , LTE 100 Mbps / 50 Mbps (Cat. 3) , LTE 150 Mbps / 50 Mbps (Cat. 4) , LTE 300 Mbps / 50 Mbps (Cat. 6) data links

SIM

Nano-SIM (4FF)

Cellular Antenna

Internal antenna

Call Alert Sound

64-chord melody

Complementary Phone Services

Voice transmission , Voice speaker , Vibrating Alert , Speakerphone , ANC , HD Voice , Voice over LTE (VoLTE)

Cellular Controller

MediaTek MT6769V

Dual Cellular Network Operation

Dual standby

Sec. Supported Cellular Networks:

GSM 850MHz (B5) , GSM 900MHz (B8) , GSM 1800MHz (B3) , GSM 1900MHz (PCS, B2) , UMTS 2100MHz (Band I, IMT) , UMTS 1900MHz (Band II, PCS) , UMTS 850MHz (Band V, CLR) , UMTS 900MHz (Band VIII) , LTE 2100 MHz (Band 1) , LTE 1800 MHz (Band 3) , LTE 850 MHz (Band 5) , LTE 2600 MHz (Band 7) , LTE 900 MHz (Band 8) , TD-LTE 2000 MHz (Band XXXIV) , TD-LTE 2600 MHz (Band 38) , TD-LTE 1900 MHz (Band 39) , TD-LTE 2300 MHz (Band XL) , TD-LTE 2500 MHz (Band XLI)

Sec. Supported Cellular Data Links:

GPRS (Class unspecified) , EDGE (Class unspecified) , UMTS 384 kbps (W-CDMA) , HSUPA (Cat. unspecified) , HSUPA 5.76 Mbps (Cat. 6) , HSUPA 11.5 Mbps (Cat. 7) , HSDPA (Cat. unspecified) , HSPA+ 21.1 Mbps (Cat. 18) , DC-HSDPA 42.2 Mbps (Cat. 24) , LTE (Cat. unspecified) , LTE 100 Mbps / 50 Mbps (Cat. 3) , LTE 150 Mbps / 50 Mbps (Cat. 4) , LTE 300 Mbps / 50 Mbps (Cat. 6)

Sec. SIM Card Slot

Nano-SIM (4FF)

Sec. Phone Controller IC:

MediaTek MT6769V

Upravljanje

Touchscreen Type

Capacitive multi-touch sensing screen

Touchscreen Simultaneous Touch Points

Da

Proširenja

TransFlash , microSD , microSDHC , microSD Extended Capacity

USB

USB 2.0

USB Services

USB charging , USB fast charging , USB Host , USB On-The-Go 1.3 , USB Power Delivery , USB Power Delivery 2.0

USB Connector

USB Type-C reversible

Max. Charging Power

18.0 W charging

Bluetooth

Bluetooth 5.0

Bluetooth profiles

A2DP , A2DP with aptX codec , A2DP with aptX HD codec , AVRCP , GAVDP , HFP , HID , HSP , MAP , PAN , PBA

Wi‑Fi

IEEE 802.11a , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n , IEEE 802.11ac

Wireless Services

Wi-Fi Tethering , WiDi , Wi-Fi Calling (VoWiFi)

IR

Da

FM Radio Receiver

FM radio (88-108 MHz) with RDS

Supported GPS protocol(s)

GPS (NMEA 0183)

Satellite Antenna:

Internal antenna

Complementary Satellite Services

Simultaneous GPS (S-GPS) , Assisted GPS , Geotagging , QuickGPS , NavIC

Supported GLONASS protocol(s)

L1OF

Supported Galileo service(s)

E1

Supported BeiDou system (BDS)

B1I BeiDou receiver

Navigation Controller

MediaTek MT6769V

Kamere

Camera Placement

Rear

Senzor kamere

BSI CMOS

Image Sensor Format

1/2.00

Image Sensor Pixel Size

0.80 micrometer

Camera Resolution

8000x6000 pixel

Number of effective pixels

48.0 MP camera

Aperture (W)

f/1.79

Zoom

1.0 x optical zoom

Focus

Phase-Detection Autofocus (PD AF)

Min. Equiv. Focal Length

26 mm

Recordable Image Formats

JPG

Video snimanje

1920x1080 pixel

Recordable Video Formats

MPEG4

Flash

single LED

Camera Extra Functions

Pixel unification , HDR photo , HDR video , Red-eye effect reduction , Slow motion video , Burst mode , Touch focus , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Face retouch (video) , Intelligent scene detection

Aux. Camera Image Sensor

BSI CMOS

Aux. Cam. Image Sensor Format

1/4.00

Aux. Cam. Image Sensor Pixel Size

1.12 micrometer

Aux. Camera Number of Pixels

8.0 MP aux. cam

Aux. Camera Aperture (W)

f/2.20

Aux. Camera Extra Functions

HDR photo , Burst mode , Panorama Photo , Face detection , Intelligent scene detection

Aux. 2 Camera Image Sensor

BSI CMOS

Aux. 2 Cam. Image Sensor Pixel Size

1.75 micrometer

Aux. 2 Camera Number of Pixels

1.9 MP aux. 2 cam

Aux. 2 Camera Aperture (W)

f/2.40

Aux. 2 Camera Focus

Contrast Detection Autofocus (CD AF)

Aux. 2 Camera Extra Functions

HDR photo , Burst mode , Macro mode , Intelligent scene detection

Aux. 3 Camera Image Sensor

Mono CMOS

Aux. 3 Cam. Image Sensor Pixel Size

1.75 micrometer

Aux. 3 Camera Number of Pixels

1.9 MP aux. 3 cam

Aux. 3 Camera Aperture (W)

f/2.40

Aux. 4 Camera Image Sensor

Ne

Aux. 4 Camera Focus

Ne

Secondary Camera Placement

Front

Secondary Camera Sensor

BSI CMOS

Secondary Image Sensor Format

1/3.06

Secondary Image Sensor Pixel Size

1.12 micrometer

Prednja kamera

4160x3120 pixel

Secondary Camera Number of pixels

13.0 MP sec. cam

Secondary Aperture (W)

f/2.25

Secondary Recordable Image Formats

JPG

Secondary Video Recording

1920x1080 pixel

Secondary Recordable Video Formats

MPEG4

Secondary Camera Extra Functions

HDR photo , Slow motion video , Panorama Photo , Face detection , Smile detection , Face retouch , Face retouch (video) , Intelligent scene detection

Sec. Aux. Cam. Image Sensor

Ne

Sec. Aux. 2 Cam. Image Sensor

Ne

Senzori

Built-in compass

Da

Built-in accelerometer

Da

Built-in gyroscope

Da

Additional sensors

Fingerprint sensor , Light intensity sensor , Proximity sensor

Zaštita od prašine

Nen-standard protection

Zaštita od vode

Nen-standard protection
