Huawei Honor 8X Max Standard Edition Dual SIM TD-LTE CN 64GB ARE-AL00 (Huawei Aries)

Osnovno

Datum izlaska

2018-09-11

Brend

Huawei

Model

Honor 8X Max Standard Edition Dual SIM TD-LTE CN 64GB ARE-AL00

Najavljen

2018 Sep 4

Dizajner hardvera

Huawei

Proizvođač

Huawei

Kodna oznaka

Huawei Aries

Dodatna oprema

Haptic touch feedback

Kategorija

Smartphone

Kućište

Masa

210 g

Širina

86.24 mm

Visina

177.57 mm

Debljina

8.13 mm

Zapremina kućišta

124.5 ccm

Ekran

Tip

Color IPS TFT LCD display

Dijagonala

7.12 inča

Rezolucija

1080x2244

Gustina

350 ppi

Otvor na ekranu

1-notch

Rezolucija

1080x2244

Širina ekrana

78.43 mm

Visina ekrana

162.95 mm

Horizontal Full Bezel Width

7.81 mm

Površina ekrana

12779.3 square millimeter

Display Area Utilization

83.5%

Pixel Size

0.07262 mm/pixel

Gustina piksela

350 PPI

Tip ekrana

Color IPS TFT LCD display

Dubina boja

24 bit/pixel

Number of Display Scales

16.8M

Display Dynamic Range Depth

8 bit/pixel

Osvetljenje ekrana

LED

Display Light Reflection Mode

Da

Display Subpixel Scheme

RGB Matrix (3 subpixels)

Zaštita ekrana

Da

Graphical Controller

Qualcomm Adreno 509

Dedicated Graphics Memory

0.25 MiB

GPU Clock:

430 MHz

Frame Buffer

16 KiB

A/V Out

Ne

Platforma

Sistem

Android

Čip

qualcomm-snapdragon-636-sdm636

Takt procesora

1800 MHz

Procesor

Qualcomm Snapdragon 636 SDM636, 2017, 64 bit, octa-core, 14 nm, Qualcomm Adreno 509 GPU

Tip RAM memorije

LPDDR4x SDRAM

RAM

4096 MiB RAM

Non-volatile Memory Type

Flash EEPROM

Non-volatile Memory Interface

Da

Interna memorija

61035 MiB non-volatile

Memorija

RAM

4 GB

Interna

64 GB

Baterija

Kapacitet

5000 mAh

Battery

Lithium-ion polymer (LiPo)

Nominal Cell Capacity (1st cell)

5000 mAh cell

Kapacitet baterije

5000 mAh battery

Vreme pripravnosti

510 hours

Standby Current

10 mA

Talk Time:

33.0 hours

Current During Talk

152 mA

Market Countries

China , HK

Market Regions

Asia , Southeast Asia

Mobile Operator

China Telecom Corporation Limited China Unicom Netcom Limited

Data Integrity

Final

Added

2020-11-19 15:55

Softver

Platforma

Google Android

Operativni sistem

Google Android 8.1 (Oreo)

Softverske mogućnosti

Voice Command , Navigation software , Augmented Reality (AR) , Intelligent personal assistant , Face Recognition

Zvuk

Audio Channel(s)

stereo

Microphone(s)

stereo

Loudspeaker(s):

stereo

Audio Output:

3.5mm

Mrežni opsezi

GSM 900MHz (B8) , GSM 1800MHz (B3) , GSM 1900MHz (PCS, B2) , UMTS 2100MHz (Band I, IMT) , UMTS 850MHz (Band V, CLR) , UMTS 900MHz (Band VIII) , CDMA 800MHz (BC0, 850) , TD-SCDMA 2000 MHz (B34) , TD-SCDMA 1900 MHz (B39) , LTE 2100 MHz (Band 1) , LTE 1800 MHz (Band 3) , LTE 850 MHz (Band 5) , LTE 900 MHz (Band 8) , TD-LTE 2600 MHz (Band 38) , TD-LTE 1900 MHz (Band 39) , TD-LTE 2300 MHz (Band XL) , TD-LTE 2500 MHz (Band XLI) bands

Supported Cellular Data Links

GPRS (Class unspecified) , EDGE (Class unspecified) , UMTS 384 kbps (W-CDMA) , HSUPA (Cat. unspecified) , HSUPA 5.76 Mbps (Cat. 6) , HSDPA (Cat. unspecified) , HSPA+ 21.1 Mbps (Cat. 18) , DC-HSDPA 42.2 Mbps (Cat. 24) , cdmaOne (IS-95) , CDMA2000 1xRTT (IS-2000) , CDMA2000 1xEV-DO Rel. 0 , CDMA2000 1xEV-DO Revision A , TD-SCDMA , TD-HSDPA , LTE (Cat. unspecified) , LTE 100 Mbps / 50 Mbps (Cat. 3) , LTE 150 Mbps / 50 Mbps (Cat. 4) , LTE 300 Mbps / 50 Mbps (Cat. 6) data links

SIM

Nano-SIM (4FF)

Cellular Antenna

Internal antenna

Call Alert Sound

64-chord melody

Complementary Phone Services

Voice transmission , Voice speaker , Vibrating Alert , Speakerphone , ANC , HD Voice

Cellular Controller

Qualcomm SDM636

Dual Cellular Network Operation

Dual standby

Sec. Supported Cellular Networks:

GSM 900MHz (B8) , GSM 1800MHz (B3) , GSM 1900MHz (PCS, B2) , UMTS 2100MHz (Band I, IMT) , UMTS 850MHz (Band V, CLR) , UMTS 900MHz (Band VIII) , CDMA 800MHz (BC0, 850) , TD-SCDMA 2000 MHz (B34) , TD-SCDMA 1900 MHz (B39) , LTE 2100 MHz (Band 1) , LTE 1800 MHz (Band 3) , LTE 850 MHz (Band 5) , LTE 900 MHz (Band 8) , TD-LTE 2600 MHz (Band 38) , TD-LTE 1900 MHz (Band 39) , TD-LTE 2300 MHz (Band XL) , TD-LTE 2500 MHz (Band XLI)

Sec. Supported Cellular Data Links:

GPRS (Class unspecified) , EDGE (Class unspecified) , UMTS 384 kbps (W-CDMA) , HSUPA (Cat. unspecified) , HSUPA 5.76 Mbps (Cat. 6) , HSDPA (Cat. unspecified) , HSPA+ 21.1 Mbps (Cat. 18) , DC-HSDPA 42.2 Mbps (Cat. 24) , cdmaOne (IS-95) , CDMA2000 1xRTT (IS-2000) , CDMA2000 1xEV-DO Rel. 0 , CDMA2000 1xEV-DO Revision A , TD-SCDMA , TD-HSDPA , LTE (Cat. unspecified) , LTE 100 Mbps / 50 Mbps (Cat. 3) , LTE 150 Mbps / 50 Mbps (Cat. 4) , LTE 300 Mbps / 50 Mbps (Cat. 6)

Sec. SIM Card Slot

Nano-SIM (4FF)

Sec. Phone Controller IC:

Qualcomm SDM636

Upravljanje

Touchscreen Type

Capacitive multi-touch sensing screen

Touchscreen Simultaneous Touch Points

10-point

Proširenja

TransFlash , microSD , microSDHC , microSD Extended Capacity

USB

USB 2.0

USB Services

USB charging , USB fast charging , USB Host , USB On-The-Go 1.0 , USB On-The-Go 1.3 , USB Power Delivery

USB Connector

USB Series Micro-AB

Max. Charging Power

18.0 W charging

Bluetooth

Bluetooth 4.2

Bluetooth profiles

A2DP , A2DP with aptX codec , AVRCP , HCRP , HFP , HID , LAP , MAP , PAN

Wi‑Fi

IEEE 802.11a , IEEE 802.11b , IEEE 802.11g , IEEE 802.11n , IEEE 802.11ac

Wireless Services

Wi-Fi Direct , Wi-Fi Tethering

FM Radio Receiver

FM radio (88-108 MHz) with RDS

Supported GPS protocol(s)

GPS (NMEA 0183)

Satellite Antenna:

Internal antenna

Complementary Satellite Services

Simultaneous GPS (S-GPS) , Assisted GPS , Geotagging , QuickGPS

Supported GLONASS protocol(s)

L1OF

Supported BeiDou system (BDS)

B1I BeiDou receiver

Navigation Controller

Qualcomm SDM636 iZat

Kamere

Camera Placement

Rear

Senzor kamere

BSI CMOS

Camera Resolution

4608x3456 pixel

Number of effective pixels

15.9 MP camera

Aperture (W)

f/2.00

Zoom

1.0 x optical zoom

Focus

Contrast Detection Autofocus (CD AF) , Phase-Detection Autofocus (PD AF)

Recordable Image Formats

JPG

Video snimanje

1920x1080 pixel

Recordable Video Formats

MPEG4

Flash

single LED

Camera Extra Functions

Electronic Image Stabilizer (EIS) , Video Stabilizer (EIS) , HDR photo , HDR video , Red-eye effect reduction , Slow motion video , Burst mode , Refocus , Touch focus , Macro mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Intelligent scene detection

Aux. Camera Image Sensor

Mono CMOS

Aux. Camera Number of Pixels

1.9 MP aux. cam

Aux. Camera Aperture (W)

f/2.40

Aux. 2 Camera Image Sensor

Ne

Aux. 3 Camera Image Sensor

Ne

Aux. 4 Camera Image Sensor

Ne

Aux. 4 Camera Focus

Ne

Secondary Camera Placement

Front

Secondary Camera Sensor

BSI CMOS

Prednja kamera

3264x2448 pixel

Secondary Camera Number of pixels

8.0 MP sec. cam

Secondary Aperture (W)

f/2.00

Secondary Recordable Image Formats

JPG

Secondary Video Recording

1280x720 pixel

Secondary Recordable Video Formats

3GP , 3G2

Secondary Camera Extra Functions

HDR photo , HDR video , Burst mode , Macro mode , Panorama Photo , Face detection , Face tagging , Smile detection , Face retouch , Intelligent scene detection

Sec. Aux. Cam. Image Sensor

CMOS

Sec. Aux. Camera Number of Pixels

1.9 MP sec. aux. camera

Sec. Aux. 2 Cam. Image Sensor

Ne

Senzori

Built-in compass

Da

Built-in accelerometer

Da

Built-in gyroscope

Da

Additional sensors

Fingerprint sensor , Light intensity sensor , Proximity sensor

Zaštita od prašine

Da

Zaštita od vode

Da
